Part # PL7700
Warranty 1 Year
Crystal Pure Salt System by PureLine
The PureLine Crystal Pure Salt System makes the process of chlorinating the pool a breeze for you. When your pump runs, you will be producing chlorine, ensuring a steady dose into your pool water. The more consistent your chlorine levels are in your pool, the fewer chemicals you will use overall. Free yourself and your pool guests from the itchy, dry feeling of regular chlorine. With a salt water chlorine generator, the water feels smooth and won't leave a white residue on your skin. The Crystal Pure generator cell easily plumbs in-line and has quick disconnect unions for easy access.
Features:
Click Here to View All Available Salt Systems
Crystal Pure Optional Add-On Accessory Package
The Crystal Pure Optional Add-On Accessory Package includes several convenient tools for your swimming pool salt system. The package includes a Salt Cell Cleaning Stand, Salt Test Strips, and a Dummy Cell. The Cleaning Stand simplifies cell cleaning and eliminates having to soak the cell in a bucket of muriatic acid solution. Salt Test Strips are used to accurately measure the salt level in your pool. The dummy cell is used during cell cleaning, winter, and spring startup.
Optional Add-On Accessories
This cleaning stand simplifies cell cleaning and eliminates having to soak the cell in a bucket of muriatic acid solution. This Cleaning stand is used for PureLine Crystal Pure salt cells. You should clean your salt cell every 2 months to avoid calcium build up on your salt cell. By cleaning your salt cell regularly you will prolong the life of the cell. Also if you get too much calcium build up on the salt cell then the system will stop producing chlorine, regular cleanings ensure that your salt system will not stop producing chlorine.
Order Your Salt Cell Cleaning Stand
Salt Test Strips are used to accurately measure the salt level in your pool. The Crystal Pure Salt System does measure and give salt readout levels on the power supply however it is nice to have salt test strips upon startup of your Salt System. During startup up you will use your test strips to make sure that you add the correct amount of salt to your pool, it is also good to be able to compare the salt readings on the power supply to those of the salt test strips to make sure the system is giving accurate salt readings.
Straight Pipe Place Holder - Dummy Cell
This straight pipe holder also called a dummy cell is used for several scenarios which we have listed below.
Winter: It is suggested that in areas of the country that you close your pool for the winter that you replace your normal cell with this dummy cell, the reason being is that the standard cell is expensive and by removing the standard cell you will prolong the cell's life.
Cell Cleaning: When you remove your normal cell for cleaning it is nice to have the dummy cell as you can replace the normal cell with the dummy cell so you continue to filter your pool while you clean your cell.
Spring Start-Up: The dummy cell is great to use during spring start up as quite often the pool can be quite dirty and you don't want large dirt and debris to get lodged in your standard salt cell.
Order Your Dummy Cell
Disclaimer:
All manufacturers’ names, brand names, trademarks, images, symbols, descriptions, and part numbers are used herein for reference purposes only.
My chlorinator stopped working. I purchased a new circuit board but it is still not working. I'm looking for a TCELL15 with the power center. Is this what I need. does it wire up on 220 volts?
Reply
Ronnie, This is a complete salt system (cell and power center). It can be wired for either 230v or 115v. The TCELL15/GLXCELL15 is a replacement cell for the Hayward Aquarite. So if you have a Hayward Aquarite and it is time to replace your salt cell then you would go with the TCELL15/GLXCELL15. If you are looking at replacing your entire salt system then the Crystal Pure would be one of several Salt Systems you could go with. You can view the Hayward Salt System here.
Reply
Is this compatible with a concrete pool / spa combo? I have an existing pool and am replacing all pumps / filter / heater. Anything else required to convert to a saltwater system?
Reply
This system is compatible with concrete, fiberglass & vinyl lined pools. Additional equipment is not required for the salt system.
Reply
Will this work with my existing cartridge type filter ?
How often does the salt cell need to be replaced ?
Reply
Paul, this system can work with your existing filtration system as long as none of your equipment is made of stainless steel. Typically 3-5 years you'll need to replace a cell on a salt system.
Reply
Less than 1 hr
Screwdriver, Wrench Set
25 2
4 to 8 hrs
Adjustable Wrench
25 2
Converted my 24k gallon pool from regular chlorine to saltwater using the purline salt system kit. The kit arrived quicky and the directions were very easy to understand. I did a complete remodel of my pools plumbing so the install went very easy. Once running the generator worked perfectly. Make sure water is balanced and stabilizer is at the right level and you’re good to go. Would definitely buy again.
4 to 8 hrs
Table electric saw , primer and glue for high pressure PVC
26 3
Hired electrician to run electrical dedicated line 50amp.
Put new schedule 40 PVC 2" with sweep elbows from filter to water in on heater. Tied in a inline zinc sacrificial metal in the same line.
Water out plumbing to a check valve 2" diameter then to a salt water generator then to a flow sensor. 16" before flow sensor, SWG acts as a 16" straight flow then 4" after flow sensor into a sweep elbow to the return lines to pool.
Turned on pump check pressure , check for leaks. Looks good, turned on breaker to heater, came on, set to pool mode and set temperature. Outside temp was 65 degrees at night, raised temperature 5 degrees in 8 hours. Will be quicker when weather warms up
Make sure heater, pump, zinc anode and salt water generator is bonded.
Less than 1 hr
Screwdriver, Pliers
25 3
Replaced my Hayward AquaRite with this system. Was very simple as the setup is exactly the same as the Hayward. It was a matter of simply connecting the wires to the same connections that the Hayward had. The cell size was the same as my T-15 so that was a simple swap as well. I completed this installation in about 25 minutes.
Less than 1 hr
Screwdriver, Pliers, Socket Set
26 2
Replacement was simple. Shut off power to old unit. Disconnected two wires and the ground wire. Hung the Crystal Pure unit and reattached the power and ground. Turned power back on and was immediately generating chlorine with the salt generator that was in place. Price was great, delivery as promised.
Less than 1 hr
Screwdriver, Pliers, Large channel lock pliers
25 1
Had 2 Hayward salt cell systems on ~40,000 gallon pool and replaced them with 1 INYO 40,000 salt cell which seems to be working fine. Easy installation. Same size as Hayward cell so no plumbing required and electrical connection was a breeze. Good instructions for my 240v wiring.
1 to 2 hrs
Hacksaw
30 0
Salt system came as sold. Packing was perfect and professional. With a few hand tools and a couple of hours time, I was ready for the operation of my new pureline salt system! I would recommend this over the competitors name brand for sure.
2 to 4 hrs
Screwdriver, Pliers, Adjustable Wrench
34 1
I converted my inground pool to a salt water system and it was the best investment I have made. After years of paying hundreds of dollars each season I finally said enough is enough and decided to convert the system. I seen this 40,000 gallon system on this site which was more than enough for my pool at a great price. I am pretty handy so I figured I would give it a shot. With the great instructions I received it took me just a few hours to do. I was hesitant at first since I never did anything like this but it came out great and works excellent. I saved hundreds and see much stress and time. I would recommend anyone thinking about doing this to go for it. The difference between salt and clorean is unbelievable. My family loves it. I say just do it.
1 to 2 hrs
Screwdriver, Voltage Tester
30 2
When I put a SCG on our above ground pool when I installed it, I couldn't believe the ease of operation. After moving recently to a house with a traditional in-ground pool that didn't have one, I knew we would need to change that. Before we even closed on the house, I identified that I wanted the Pureline SCG by reading every review and question and doing even more research online on other websites. Just Google That Stuff!
First of all, I can't emphasize enough the planning and preparation. We started by determining how much salt we would have to add and I ordered online from a local hardware store when they were having a sale. We needed 24 - 40# bags. We actually added the salt approximately a week before installation--plenty of time to allow it to dissipate. Then we planned the installation and I assemble the tools & materials I would need: PVC Glue, Reciprocating Saw, tape measure, voltage tester, wire nuts, flexible conduit, wire, outlet box.
One evening when I got home from work the Pureline PL7700 was there and I went about getting it plumbed into my return line. I purchased a corrosion resistant check valve from INYOPOOLS.COM to put before the SCG. After measuring one more time, I turned off the pump at the breaker and cut my 2" PVC line and removed the section of pipe I would need to install the check valve, Pureline PL7700, and flow switch (in that order). After cutting it out, I began the process of gluing in the check valve on one side and the flow switch on the other side. I used Christy's Hot Blue Glue and then I measure one more time to cut my nipples for the screw ends for the SCG and added those. I allowed those to dry for a bit before I hand tightened the SCG cell inline. Turned the pump back on and checked for leaks and was done for the night. Total time, about an hour.
The next morning I cut some blocking to add in between the studs to mount the control box at eye-level above the pump. Then I removed the plate on the pump electrical & tested the voltage (240). At this point I decided to swap the single gang box for a double gang. I then wired a hot, neutral and ground coming out of my power supply for the pump and put those wires inside a new flexible conduit and supplied power to the Pureline control box. I secured the new wiring to the appropriate terminals, plugged in the flow switch and the wire to the salt cell & activated it.
2 to 4 hrs
Screwdriver, Nut Drivers, Socket Set, Saw and Slipjoint Pliers
28 3
The Most Helpful Review
69 0
(5 out of 5 stars) Works as advertised
Reviewed By: Ringo from Chandler, AZ ()
Pros: It works!!
Cons: None yet.
This is/was my first salt system install so I have nothing to compare to. The install was pretty straight forward, did it all myself in a half a day or so. Most of the time was spent doing the electrical. Took my time as one always should when doing wiring. The plumbing (which I don't normally do) was fairly easy and consumed an hour or so of the install time. Patience and planning should be applied here as well, or you'll find yourself doing more plumbing than you had hoped. Lots of valuable install info available here on the Inyopools site in the "how to guides" as well. The unit appears to be built/manufactured pretty solid, no complaints there. It's making chlorine, what it's made to do. Off to the pool....Enjoy!!
Was this review helpful to you?
The Most Recent Reviews
25 1
(5 out of 5 stars)
Reviewed By: Inyo Customer ()
wonderful
Was this review helpful to you?
34 1
(3 out of 5 stars) Cell did not last very long
Reviewed By: Inyo Customer ()
Cell did not last very long, replacement cell costs as much as I paid for the entire unit.
Was this review helpful to you?
43 0
(5 out of 5 stars) GREAT alternative to the popular Hayward Aqua Rite
Reviewed By: Inyo Customer ()
This is a GREAT alternative to the popular Hayward Aqua Rite. it’s about half the price of the name brand and it performs just as well. I actually purchased a second one and installed it on a friend's pool. If you have basic PVC skills and general handy man skills this installation is a piece of cake. I have had my system installed for around 9 months now and has kept my pool “crystal” clear! Haha. Thanks. Pool Size (Gallons) 20x40 about 25k gallons
Was this review helpful to you?
25 0
(5 out of 5 stars) Extremely Happy
Reviewed By: Inyo Customer ()
I am extremely happy with the salt system.
Was this review helpful to you?
31 0
(5 out of 5 stars) Direct Replacement
Reviewed By: Inyo Customer ()
This was a direct replacement for a hayward aquarite that was an older revision and I wouldn't be able to use any of the newer, cheaper cells. The wiring was pretty straight forward since I was merely moving the wires from one box to another. The unit works very well when it runs. I had issues getting this to make chlorine after about 2 or 3 months, where it constantly said salt was low (it wasn't) would stop generating after about 15 minutes or so. What I found was that even though I was getting enough water to the flow switch, the DE filter needed cleaned and after doing so it runs like a charm again. I have this installed with a variable speed pump, and low RPM's don't activate the flow switch, something to think about. I would buy it again but feel that there is a learning curve that this isn't something that you can set and forget right away.
Was this review helpful to you?
39 0
(5 out of 5 stars) Rated top #1 by me
Reviewed By: Inyo Customer ()
The Pureline salt system is awesome! It was an easy and exact replacement for overpriced and unreliable brand I previously had installed. Even the o-rings provided with the Pureline were far superior quality. The controller appears to not generate as much heat inside the control box as the other brand I replaced, something we look at in the southwest desert. I highly recommend anyone with other brand salt system replace them with Pureline, and the dealer was prompt in shipping and follow up.
Was this review helpful to you?
23 2
(5 out of 5 stars) Chrystal Pure has got to be the best deal overall
Reviewed By: Inyo Customer ()
I just finished installing my Crystal Pure Salt System and I’m thrilled with the results! The install was very straight forward and the components appear to be good quality. I recommend buying a tube of JB weld water repair in case you have any leaks in the PVC joints after they’re sealed. I had a few small leaks (slow drips) even though I was very precise about cementing the joints. JB weld can be added to wet applications and it works great…simply amazing stuff! I have a 15K gallon pool and purchased the 40K system which is more than enough to keep the free chlorine levels up during our brutal southern Mississippi summers. My pool had almost zero chlorine by the time the system was installed and ready to start producing so I had to boost the chlorine level by placing a few 3” chlorine tabs in the skimmer basket and using the “super chlorinate” setting for 24 hrs. My FC levels shot up rapidly in just a few hours so I brought the system back down to the 40% setting and kept it there. Last night and throughout today we’ve had a ton of rain from tropical storm Barry and I was anticipating having to add some shock to help the system keep up. I was pleasantly surprised that my chlorine levels were just like they were before the rain! I will continue to monitor and test over the next few days to see where I’m at but so far I love what I see! As for the difference in water quality, it’s night and day. The salt water feels almost silky without the chlorine smell and without burning your eyes. That alone was worth the conversion headaches and costs! This is my first salt system so I really don’t have much to compare to but I’m loving it so far! If you’re considering the conversion do your homework like I did as there are a lot of different systems. Chrystal Pure has got to be the best deal overall and I really don’t have a negative thing to say thus far. I give it 5 of 5 stars
