sorry I mean Magic lube nor glue.......how often you can do that. i mean over the
tank O ring. the when clean the filter you removed the half of the tank cover.
I mean the big gasket big O ring. assembly the entire tank.
Reply
Ideally, every time you open the tank to clean or inspect you should wipe off the old lube and put new on.
Reply
will this fit Hayward c5025
Reply
Hi, Cathy. Yes, the 4820-02 is the correct part number for the filter tank O-Ring, that is used on the Hayward SwimClear Cartridge Filter Model C5025. I would best recommend purchasing Magic Lube O-ring Lubricant 1 Oz. Teflon, to help seal and protect the O-Ring.
Reply
I NEED A SEAL FOR MY HAYWARD PRO-GRID VERTICAL DE-6000
Reply
Hi Juan, This Tank O-ring will fit the Hayward Pro-Grid DE6000 filter. You can locate other parts for that model filter via the Hayward Micro Clear D.E. Parts.
Reply
Will this fit a Hayward Micro Clear DE 3600?
Reply
Yes, the O-429 tank O-ring is compatible with the DE3600 Hayward Micro-Clear.
Reply
Will this seal work for my Hayward Swimclear model C2030?
Reply
Hi Steve, The Hayward SwimClear C2030 filter uses the Metal Reinforce Seal-DEX2422Z2.
Reply
Im looking for the large gasket for my pump model #DE4820
Reply
Hello, The O-ring, Tank - Generic (o-429) is the correct replacement gasket for the DE4820 model DE filter.
Reply
Will this gasket fit a Hayward Crystal Clear II filter housing with model number DE-LE-42054? Also if it fits...can I get it shipped overnight.
Reply
Hello Paula, Yes this O-ring, Tank - Generic (o-429) will fit, any Expedited orders placed after 1 PM EST will ship the following business day. Saturday, Sunday and National holidays are not classified as business days, for example if you placed an order via 2 Day Air on Thursday before 1 PM EST your order would be delivered in 2 business days which would mean delivery on Monday. There isn't an overnight option, there is Next day air, 2 day, 3 day, or ground shipping. Please make sure to double check your order and anything after 1pm will be processed next business day.
Reply
I have a Hayward DE4800 Micro Clear. This o-ring works at first, but after the second start up of the pump, it leaks. I re-lubed it four times and same results. I can run the pump for four days straight after I lube it up and no leaks, but once the pump sits idle after a night, the next time it starts up, it drips. It appears this new o-ring is just a hair too small in thickness for my filter. Any suggestions? Thanks
Reply
Good afternoon, The OEM o-ring for your filter is Filter Tank O-ring - DEX2400K this is the correct o-ring.
Reply
will this fit a hayward made for leslies crystal clear 42052 de filter lid
Reply
Hi. Yes, this Tank O-ring - O-429 will fit the Leslie's Crystal Clear DE Filter- 42052.
Reply
It looks like the o-ring seal for my Hayward Swim Clear filter (C2020) is INYO 4820-02. When replacing what is a good lubricant ?
Reply
Hi. That is correct, you can use the Magic Lube O-ring Lubricant 1 Oz. Teflon - 630.
Reply
I'm pretty sure this O-Ring will fit my Blue Haven Hayward filter 5520BH, Right? What is the filter cartridge repl. #? I will need 4 of these...
Reply
does this O ring fit the C3000s tank
Reply
Hi. This Tank O-ring will fit the Hayward Super Star Clear Cartridge Filter - C-3000 model.
Reply
I have a DE Pro Grid 6020 from approx. 2002. Will this fit it? The metal reinforced one DEX2422Z2 seems too small in thickness and leaks.
Reply
I have a Blue Haven Hayward filter model 4025 filter, I think? It has black steel clamp with the spring loaded nut. I received an update from Blue Haven for parts and it say c4520bhme. The o-ring currently installed is rubber without the steel reinforcement suggested by the new model number. Will this rubber seal work with my filter? Thanks for any help or assistance you can offer.
I researched and found that the inside diameter on the oem O ring was 19 7/8". The one you show is 18 7/8". This would be too small correct? Thanks for help!
Reply
Hello, In order to find the correct o-ring you will need, we will need to know the brand and the model of the filter. If you are unsure of which one you have, you can replay to this E-mail with a picture of your filter and we will be able to identify it for you.
Reply
I have a Hayward DE 6000 filter and the current o ring that seals the top and bottom leaks. Do you have an O ring that would seal properly. The O rings I find at the local pool supplies seem to be too small in diameter.
Reply
I have a DE 4800 filter. I want to replace the O ring that seal the top and bottom of the filter assembly. what size should I purchase?
john
Reply
Is the O-ring O-429 correct for an older Hayward C4000 (Star Clear)? Is the measurement 19 7/16" the INSIDE dimension/radius?
Reply
Yes, this would be the correct lid o ring for the model Hayward C-4000 filter.
Reply
Is this the proper body o-ring for a Hayward DE2420?
Reply
Yes this is the correct o-ring for a Hayward DE2420, you can also upgrade this Hayward DE Filter Heavy Duty Metal ReInforced O-Ring either will work for your filter.
Reply
will this o ring fit Hayward DEX2422Z2
Reply
how do I know what is the correct size for the tank or body o ring de6000a
Reply
Hello Audrie, this o ring part number 4820-02 is compatible with the Hayward model DE6000 Micro Clear D.E. filter and under its main image on its page is a "size" option that provides all of the dimensions that we have measured of it.
Reply
what O ring body tank can fit in De3600 hayward
Here is a link to the complete parts breakdown for your Hayward DE3600.Hayward Micro Clear D.E. Parts BreakdownThis 48020-02 is the oring for the filter tank.
Reply
Will this fit Hayward C6060 swimclear filter body?
Reply
Hello Neeru. The Aladdin Tank O-ring 4820-02 is NOT compatible with the Hayward SwimClear Multi-Element Series Filters. The correct O-ring for the Hayward SwimClear Multi-Element Filter Series is DEX2422Z2. Tank Lid Metal Reinforced O-ring - DEX2422Z2
Reply
will this fit a Hayward Progrid clear DE model number DE7220s?
thanks
Reply
Does this o-ring fit to Micro Clear DE filter Model DE720s?
Reply
Hi Jack. This does not fit your DE720S. You need this O-ring, Filter Tank, O-430 since you have the stainless steel version of this filter.
Reply
Does this seal work on the DE360S tank?
Reply
Hi Randy, this fits on the Hayward Micro Clear D.E. filters with the Duralon or Permaglass tank, but the Hayward Micro Clear D.E. Stainless Steel tank requires the 0-430 filter tank o-ring.
Reply
Will this fit my Hayward Swimclear C3025 cartridge filter housing?
Reply
Hi Scott, the Tank O-ring - O-429 will fit your Hayward SwimClear Cartridge Filter C3025 perfectly. Be sure to clean it and lubricate it when you service your filter so it lasts a long time.
Reply
would this gasket fit the Hayward de3620?
Reply
Hello Matt. The Filter Tank O-ring for Hayward ProGrid is compatible with the Hayward DE3620 Filter.
Reply
I would like to know if this O ring -429 fit my Hayward DE 6020 filter, my filter was made before 2009.
Thank you.
Reply
Hello Jana, yes this is the correct tank lid o ring for the Hayward Pro Grid DE filter model DE6020 Pre 2009 models.
Reply
Will this seal fit my old Hayward super star clear c-4000 filter? My seal seems to be more of a "D" shaped ring vs an "O" ring but maybe it has compressed over time and that is why it is beginning to leak? Thanks
Hi Tony, the 4820-02 Filter Tank O-ring should be perfect for your Hayward SuperStar filter. Your old o-ring has the "D" shaped profile as a result of being compressed over the years. Get the new o-ring, put some lubricant on it, clean the sealing surfaces and you'll be good to go!
Reply
