By Speck Pumps


Details

Top

Model # 2195378007

Warranty 2 Year

Manufacturer Code IG273-1750F-000

Alternate Part #'s 95-X

Product Description



Commercial Pool Pump

The Speck Model 95 is setting new standards with many firsts in the industry. Look for the largest one piece plastic casing design with integrated strainer basket, easy on/off two-piece lid, and 4" quick disconnect unions. These features combined with our unique mechanical seal results in a medium head pump with the "highest flow" of any one piece plastic pump in the market today. This pump is ideally suited for high-rate sand filter applications as well as water features. Speck's high quality continues in the Model 95 with positive advances to benefit the consumer and the environment.

Features

  • Large, one-piece housing design with integrated strainer basket and easy on/off two-piece lid.
  • Quiet and efficient medium head pump performance
  • This high performance pump comes complete with our unique mechanical shaft seal that allows the pump, if mistreated, to run dry for up to one hour.
  • The pump can be used for pool water with a salt concentration of up to 5000 ppm. (For a higher concentration please call 1-800-223-8538)
  • Suction and discharge are equipped with 4" quick disconnect unions for easy installation and maintenance.
  • Wrench for unions and lid is included with each pump.
  • Flanges are available upon request.
  • Heavy duty energy efficient totally enclosed fan cooled (TEFC) motor.
  • Motor is easy to remove without disturbing the plumbing. Reusable o-rings throughout.
  • Two year warranty on the motor and all pump parts, including normal wear of the mechanical seal.
  • Every pump is performance tested before leaving the Speck factory.




Speck



Speck

Product Specifications

HP:
7.5 HP
Speed:
Single
Service Factor:
1.15
Volts:
208 - 230/460 V
Max Pool Size:
4 gal.
Weight:
141 lbs.
Top

?     Asked on 5/2/2017by Inyo Visitor

on the 208 volt 3 phase 7.5 Hp speck model # 95-X what should the amperage be
 Reply

A  Answered on 5/2/2017 by InyoPools Product Specialist Lennox H.

Hi. The Speck 95-X Pump at 208 volts uses 22.0 S.F. Amps or 19.0 Full Load Amps.
 Reply


?     Asked on 12/16/2020by Inyo Visitor

How much gallon per minute is the pump and recommended filter size
 Reply

A  Answered on 12/17/2020 by InyoPools Product Specialist Joe S.

Good afternoon,Attached is the flow chart that will determine the GPM's of this unit based on total feet of head. Here is our How To Size a Pool Filter.
 Reply
