$89.01

Qty:

By Pentair Pool Products


Details

Top

Part # 5003-031

Manufacturer Code 356012

Dimensions 8.25" L x 8.25" W x 2" D

Alternate Part #'s 356012, 622639, 788379659363, PAC-101-6012, 35-110-1148, PEN356012

Product Description

Pentair Seal Plate - 356012

Frequently Bought with Seal Plate

Shaft Seal 5250-104

Shaft Seal Lubricant

Top

?     Asked on 1/1/2019by kalliana Krishnan

does this flange fit all Pentair superflow VS Poo; pumps? and why is there is crusting around the flange? is it calcium?

 Reply

A  Answered on 1/2/2019 by InyoPools Product Specialist Kevin G.

Hello, yes this will work for all Superflow VS pumps. In regards to the build-up, that will most likely be a calcium buildup and is just cosmetic, unless there is a leak.
 Reply


?     Asked on 12/16/2021by John Gracia

I would like to know if the seal plate is the correct replacement for the Pentair Superflo 1HP motor. I need to remove motor and install a new seal plate. Thanks.

 Reply

A  Answered on 12/17/2021 by InyoPools Product Specialist Stephen B.

Thank you for contacting Inyo Pools, Yes this is the correct seal plate. Seal Plate- Almond - 356012 I would replace all the seals a gaskets while it is apart Tune Up Kit Pentair SuperFlo/Sta-Rite SuperMax - GOKIT7
 Reply


Top
Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, Socket Set, Adjustable Wrench

2     0

Forgot to remove drain plugs (x2) from the pump assembly, temp. fell to 10*, water in pump froze & ruptured seal.

Written on 2/10/2018 by Guest

Removed 4 bolts on either side of seal. Removed end of pump to hold shaft while removing impeller. Removed 2 rubber O rings on impeller housing, cleaned & lubed with pool & spa lube. Removed, cleaned & lubed 'spring' pressure seals @ hub of shaft. Reassembled in reverse order, primed pump, opened all valves & turned on pump. Water began to flow within a minute.

Were these instructions helpful?


Top

Review Summary

 (Average 4.67  out of 5 stars)
3 Rating
5 star:

(2)
4 star:

(1)
3 star:

(0)
2 star:

(0)
1 star:

(0)

The Most Recent Reviews
