?     Asked on 6/23/2015by Inyo Visitor

Can this switch be used on a Century BN34V1 motor?
 Reply

A  Answered on 6/24/2015 by InyoPools Product Specialist Lennox H.

Hi, The Toggle-two Spd Switch (18313301) can be used on the 1-1/2 HP 2 Speed 230V Thru Bolt Motor (BN34V1).
 Reply


?     Asked on 4/29/2016by carolyn

can this be used on a bn60 7-186022-03 motor whose replacement motor is now a BN 50vi? my toggle broke and I need a new toggle
 Reply

A  Answered on 4/30/2016 by InyoPools Product Specialist Lennox H.

Hi Carolyn, This Toggle Switch will fit the BN60 motor.
 Reply


?     Asked on 5/12/2016by Mike

Will this switch on a waterway 2.5 horsepower pump. My toggle switch has broken off. Thanks for all of your help! The products I've purchased from you has always worked GREAT!
 Reply

A  Answered on 5/17/2016 by InyoPools Product Specialist Lennox H.

Hi Mike, This Switch can work on a certain Waterway pumps. However without know which model you have we're unable to confirm. If you can provide the model number or motor no. we can confirm.
 Reply


?     Asked on 6/10/2016by Justin

will this switch work on a century bn37?
 Reply

A  Answered on 6/19/2016 by InyoPools Product Specialist Lennox H.

Hi Justin, This Toggle Switch can be used with the BN37 motor.
 Reply


?     Asked on 7/14/2016by Vincent E cavaliere

Will this switch work with a Waterway pump Model PH2150-6p..2 speed..if not where can I get one?.. Thanks
 Reply

A  Answered on 7/17/2016 by InyoPools Product Specialist Lennox H.

Hi Vincent, This can work with the Waterway PH2150-6P model pump depending on the end cap that you have. This will not work if you have a switchless motor.
 Reply


?     Asked on 8/23/2016by Dan Lee

Will this switch work with the 56 frame B 2982 Century motor?
 Reply

A  Answered on 8/26/2016 by InyoPools Product Specialist Lennox H.

Hi Dan, The correct toggle switch assembly for the B2982 motor is p/n 2512558-001.
 Reply


?     Asked on 6/5/2017by Haley

Probably a silly question, but how hard it is to install this separately? I will be ordering a BN50 soon, but the last replacement pump I order through another company already had the switch combined with it.
 Reply

A  Answered on 8/9/2017 by InyoPools Product Specialist Alex V.

Haley, The switch is not difficult to install. You can use this how to guide for reference.
 Reply


?     Asked on 7/7/2017by pete herrmann

I just purchased a bn36 motor and need a 2 speed toggle switch only.my switch broke off on my original motor.
 Reply

A  Answered on 7/9/2017 by InyoPools Product Specialist Lennox H.

Hi, Pete. This 2-SPD Toggle Switch - 18313301 will fit the Century BN36 Motor.
 Reply


?     Asked on 10/1/2017by Siegfried Zapp

Does this switch work inplace of Intermatic switch #RC 2343 pt ? Thank you! Siegfried Zapp,I don't mind the manual switching.
 Reply

A  Answered on 10/3/2017 by InyoPools Product Specialist Lennox H.

Hi, Siegfried Zapp. This Toggle Switch Assy can be used if you have a compatible motor bypassing the RC2343PT controller.
 Reply


?     Asked on 10/5/2017by Siegfried Zapp

This switch replaces Intermatic air switch #RC 2343?,does it include installation installation instructions? Thank you, Siegfried Zapp
 Reply

A  Answered on 10/5/2017 by InyoPools Product Specialist Hector F.

It should contain the wiring diagram but if not you can view that by clicking here
 Reply


?     Asked on 5/10/2018by Jack Robinson

How does the 18313301 Switch wire into A O Smith motor B2979
 Reply

A  Answered on 5/11/2018 by InyoPools Product Specialist Lennox H.

Hi, Jack. This Toggle Switch Assy - 18313301 is not compatible with the B2979 motor, you will need the 56Y 2-Speed Toggle Switch Canopy - 2512558-001. Use this link for Wiring Instructions
 Reply


?     Asked on 6/7/2018by Carl

Will this fit a Century 1.5 HP SPL (2 SPD)
 Reply

A  Answered on 6/8/2018 by InyoPools Product Specialist Lennox H.

Hi, Carl. Yes, this will fit a Century BN Series 48Y Dual Speed motors.
 Reply


?     Asked on 6/18/2018by Micki

Will this fit a Century Flex-48 HP:1.0 SPL (2 spd) motor?
 Reply

A  Answered on 6/18/2018 by InyoPools Product Specialist Patrick P.

Hi Micki, Yes this would be the correct replacement switch for a Century Flex-48 HP:1.0 SPL (2 spd) motor
 Reply


?     Asked on 6/23/2018by Dan

I was looking to replace my SP1500FT Microprocessor Pump Timer but see it is no longer available. The Q&A on that page directed me here. My pump is the Hayward SP1515-Z-1-EFTC. I believe it is single speed only. Will this 2 speed switch still work properly? If not, what is recommended?
 Reply

A  Answered on 6/23/2018 by InyoPools Product Specialist Lennox H.

Hi, Dan. You will need the On/Off Switch Assembly - 18374501 since your motor is single speed.
 Reply


?     Asked on 5/2/2019by Donald Brien

I have a Hayward as seen in the pictures. Is there a way I can convert my single speed motor to a 2 speed motor or will I need to replace the motor altogether.

 Reply

A  Answered on 5/2/2019 by InyoPools Product Specialist Matt S.

Unfortunately, you will not be able to make that single speed motor a two-speed. The only route is to start with a whole new dual speed motor; which would be the BN50V1. The shaft seal to complete the motor installation is 5111-03.
 Reply


?     Asked on 6/3/2019by Doug

Will this switch fit the Hayward SP3215X202 2 HP Pool Pump, Dual-Speed, TriStar? Thanks
 Reply

A  Answered on 10/2/2019 by InyoPools Product Specialist Steve M.

Doug, yes, the Two-Speed Toggle Switch Assy. - Lo/Off/Hi - 18313301 will fit your SP3215X202.
 Reply


?     Asked on 8/6/2019by Frank

Will this toggle switch work on the A.O. Smith 1.5 HP Round Flange 56J Dual Speed Full Rate Motor - STS1152R?
 Reply

A  Answered on 8/6/2019 by InyoPools Product Specialist Michelle B.

Hello,This will be the correct toggle switch,http://www.inyopools.com/Products/00201352046334.htm
 Reply


?     Asked on 10/1/2019by J. Martin Clauder

Will this work on a Century A.O. Smith B977 56J C-Face. If not, do you have a part that will. Thank you.
 Reply

A  Answered on 10/2/2019 by InyoPools Product Specialist Jessica C.

Hi, The switch you will need for the B977 motor is the Toggle Switch and Canopy Kit for 56Y 2-Speed - 2512558-001
 Reply


?     Asked on 4/19/2020by Angela

I don't need the entire assembly, I just need the appropriate toggle switch for a Waterway 2 Speed 115V 1.5 Hp Spa Pump that I use for my pool.
 Reply

A  Answered on 12/23/2020 by InyoPools Product Specialist Megan C.

We will need the motor model, CAT, or Part number to check for the toggle, a majority of motors require the canopy with a toggle to be ordered. If the motor is the originally installed with the Waterway pump you will need to contact them directly at 805-981-0262 for the part number, they have their motors private labeled and will need to provide it.
 Reply


?     Asked on 8/11/2020by Manny

Will this work on a Century motor 7-181327-03. Frame is R48Y
 Reply

A  Answered on 8/11/2020 by InyoPools Product Specialist Lennox H.

Hi, Manny. Yes, this Toggle Switch Assy - 18313301 will fit the Century motor 7-181327-03.
 Reply


?     Asked on 5/8/2021by Kim

I need the switch and an outside cover for a MagneTek Century AC motor. Part 7 193077 01. It's for a Hurricane Jucuzzi pump. Do you have one?

 Reply

A  Answered on 5/10/2021 by InyoPools Product Specialist Patrick P.

Hi Kim, This switch on this page is the correct replacement switch for the motor included in your photo.
 Reply


?     Asked on 8/28/2022by Kenneth Gass

Hello, please see the attached picture and let me know if this 2 speed switch is the correct one.

 Reply

A  Answered on 11/16/2022 by InyoPools Product Specialist Hector F.

Hello Kenneth, the correct toggle switch for your motor part number B975 is part number 2512558-001. It is currently out of stock however you can add yourself to the "notify me when in stock" list on the items page. You can also use a secondary dual speed timer part number T106R which piggy backs off of the main pool pump timer.(most pump use one)
 Reply


?     Asked on 10/2/2022by Sasha Markovic

Will this switch work with a Century 1.5 HP Thru-Bolt 48Y Dual Speed Motor - BN50V1?
 Reply

A  Answered on 10/3/2022 by InyoPools Product Specialist Hector F.

Hi Sasha, yes this toggle switch is compatible with the motor model BN50V1. I also have emailed you a quote attached to your account with us that you can convert to an order if you would like as well.
 Reply


?     Asked on 6/4/2023by Jasso

Is this 2-Speed toggle switch compatible with my Hayward Power-Flow Matrix 1081 Pool Pump Duty motor? See attached picture. Thank you.

 Reply

A  Answered on 6/4/2023 by InyoPools Product Specialist Hector F.

Hello Jasso, You will need the On/Off Switch Assembly - 18374501 since your motor is single speed. I have also emailed you an estimate that you can convert to an order if you would like. Item is currently in stock and ready to ship.
 Reply
